Presentation
- Best driving and lifting experience
- Ultimate versatility
- Minimal maintenance and downtime
- Longer lifetime
Specifications
Best driving and lifting experience
- AC powered
- Precision driving control
- Smooth proportional motions
- Excellent turning radius
Ultimate versatility
- Pass through standard doorways
- Mobile pothole protection
- Indoor - outdoor rated
Minimal maintenance and downtime
- Maintenance free AC motors
- Easy access swing out trays
- Haulotte Activ'Screen (onboard diagnostics)
- Smart transportability
Longer lifetime
- Haulotte Activ'Energy Management takes care of your batteries
- Extreme durability
- Optimized total cost of ownership
| Working height | 24 ft 11 in |
| Platform height | 18 ft 11 in |
| Driveable at full height up to | 18 ft 11 in |
| Lift capacity - inside | 500 lb (2 pers.) |
| Lift capacity - outside | 500 lb (1 pers.) |
| Lift capacity - extension | 265 lb |
| Platform length - outside | 5 ft 8 in |
| Platform length - extended | 8 ft 6 in |
| Extension length | 2 ft 10 in |
| Platform width - outside | 2 ft 5 in |
| Platform size - extended | 8 ft 6 in x 2 ft 5 in |
| Height - stowed | 6 ft 6 in |
| Overall width | 2 ft 7 in |
| Length | 6 ft 3 in |
| Wheelbase | 4 ft 6 in |
| Ground clearance | 4 in |
| Ground clearance - pothole guards deployed | 1 in |
| Drive speed | 0.3 - 3,1 mph |
| Gradeability | 25 % |
| Tilt alarm | 1.5° / 3° |
| Turning radius - outside | 4 ft 11 in |
| Non-marking tires | 12.5 x 4.13 |
| Batteries | 24 V - 225 Ah (C20) |
| Hydraulic system capacity | 1.6 gal |
| Weight | 3,505 lb |
- Haulotte Activ'Energy Management: Smart CAN charger
- 24 V electric drive brushless AC motors
- Battery level indicator on upper and lower control boxes
- Haulotte Activ’Screen (battery charge, hourmeter, service alerts & failure icons in code or in full text...)
- Mobile pothole guards
- 2 swing out trays
- Lateral fork lifting pockets
- 2 front steering and 2 rear driving wheels
- Electrical or manual brake release system
- Non-marking tires
- Motion alarm
- Motion flashing light
- Swing-door gate
- Manual or automatic battery waterfilling systems
- Front platform extension
- Mobile upper control box
- Haulotte Activ'Energy Management: automatic or manual battery waterfilling system
- Folding guardrails
- Cold weather hydraulic oil
- Telematics solutions
- Dual flashing beacons
- Work light
- Panel carrier
- AGM maintenance-free batteries
- Pipe cradle
- Secondary guarding system
- Lithium-Ion maintenance-free batteries
