Presentation
- Great productivity & performance
- Minimized total cost of ownership
- Optimal safety
Specifications
Great productivity & performance
- Dual load capacity: 550 lbs - 770 lbs restricted (standard)
- 4 wheel drive for excellent rough terrain capabilities
- Quick & simultaneous movements
Minimized total cost of ownership
- Haulotte Activ'Screen diagnostic display for onboard fault & service alerts
- Easy access to components
- Haulotte Stop Emission System reduces engine and component wear
- Engine and drive train optimizes all-terrain performance
Optimal safety
- Smooth & proportional movements for greater precision
- Haulotte Activ’Shield Bar prevents crushing risks
- Haulotte Activ’Lighting System illuminates the machine for safe loading in low visibility (option)
| Working height | 52 ft 3 in |
| Platform height | 46 ft 3 in |
| Horizontal outreach | 42 ft 8 in |
| Lift capacity | 550 lbs (2 pers.) - option 770 lbs |
| Platform size | 8 ft x 3 ft |
| Length - stowed | 30 ft 1 in |
| Length - transport | 21 ft 11 in |
| Width | 7 ft 6 in |
| Height - stowed | 8 ft 1 in |
| Height - transport | 10 ft |
| - Vertical jib rotation - | 133° (+68°/ -65°) |
| Turret swing | 360° continuous |
| Tailswing | 37 in |
| Wheelbase | 7 ft 9 in |
| Ground clearance | 13 in |
| Tilt alarm | 5 ° |
| Drive speed | 3.2 mph |
| Gradeability | 45 % |
| Turning radius - outside | 16 ft 9 in |
| Tires - solid rough terrain | 33.5 x 13.4 in |
| Engine | Kubota 18.5kW Tier4f |
| Weight | 17,177 lb |
- Haulotte Stop Emission System: automatically turns the engine off & on
- Haulotte Activ'Screen: on-board diagnostics
- 4 Wheel Drive
- Oscillating axle
- Differential : permanent limited slip & operator controlled locking rear
- Smooth & proportional movements
- Up to 4 simultaneous movements
- Telematics solution
- Cured-on solid tires
- Swing out engine tray
- Upper control box protection and tool tray
- Sound and light alarm for tilt and load
- All motion alarm and flashing beacon
- Haulotte Activ'Lighting System
- Hydraulic generators 3.5kW or 6.5kW
- Glazier pack
- Pipe rack kit
- Air-line to platform
- Dual USB plug in basket
- Non-marking tires
- Cold weather package
- Hydraulic oil cooler
