Presentation
- Performance & productivity
- Safety and comfort
- Minimized Total Cost of Ownership
Specifications
Performance & productivity
- Dynamic & comprehensive working envelope
- Automatic vertical platform rise
- Outstanding rough terrain capabilities
- Unrestricted platform capacity 550 lbs
- Dual load capacity 550 - 770 lbs (optional)
Safety and comfort
- Fully proportional and simultaneous movements
- Haulotte Activ'Lighting System for safe loading/unloading in low visibility conditions
- Haulotte Activ'Shield Bar 2.0
Minimized Total Cost of Ownership
- Haulotte Activ'Screen diagnostic display for on board fault & service alerts
- Haulotte Stop Emission System automatically turns the engine off & on
- Easy access to all maintenance components
- Exclusive modular platform, quick and easy to repair
| Working height | 86 ft 1 in |
| Platform height | 80 ft 1 in |
| Horizontal outreach | 57 ft 5 in |
| Up and over clearance | 30 ft 6 in |
| Lift capacity | 550 lb (2 pers.) - option 770 lb |
| Platform size | 8 ft x 3 ft |
| Length | 38 ft 8 in |
| Width | 8 ft 2 in |
| Height - stowed | 9 ft 9 in |
| Storage / transport length | 30 ft 10 in |
| Storage / transport height | 9ft 9in |
| Vertical jib rotation | 133° (- 65° / + 68°) |
| Platform rotation | 180 ° |
| Turntable rotation | 360° continuous |
| Tailswing | 30 in |
| Wheelbase | 9 ft 2 in |
| Ground clearance | 19 in |
| Tilt | 4 ° |
| Drive speed | 3.1 mph |
| Maximum wind speed rating | 28 mph |
| Gradeability | 45 % |
| Tires - solid rough terrain | Cured on 40.4 x 14.4 in |
| Turning radius - outside | 21 ft 6 in |
| Power source | Kubota 48.6 kW (66 hp), T4f |
| Weight | 34,100 lb |
| Hydraulic tank capacity | 37 gal |
| Fuel tank capacity | 21 gal |
| Ground clearance - mini | 0 ft |
| Ground clearance - maxi | 0 ft |
- Embedded diagnostic system Haulotte Activ'Screen on lower control box, with color screen
- Haulotte Activ'Shield Bar 2.0 secondary guarding system
- Haulotte Activ'Lighting System
- Haulotte Stop Emission System: automatic engine stop system
- Telematics solutions
- 4 wheel drive, 4 wheel steer
- Front oscillating axle
- 4 simultaneous & proportional movements
- Automatic differential wheel lock
- Upper control box cover
- Ruggedized tool tray
- Large modular platform 8 ft x 3 ft with drop bar entry gate
- AC power to platform (110 / 230V)
- Swing out engine tray
- Sound and light alarm for tilt and load
- Rotating beacon
- Travel alarm
- Electric pump system and emergency descent
- 12 V battery / electrical control system
- Engine pre-heater with light indicator
- Low fuel level indicator (upper & lower control box)
- Non-marking tires
- Dual load capacity 550 / 770 lbs
- 37 mph wind speed
- Air line to platform
- Hydraulic generator 3.5 kW
- Biodegradable hydraulic oil
- Hydraulic oil cooler
- Cold weather kit / arctic weather kit
- Pipe cradle pack
- Glazier pack
- Work light pack
- Battery circuit breaker
