Presentation
- Maximum productivity
- Excellent rough-terrain capabilities
- Optimized cost of ownership
- Optimal safety
Specifications
Maximum productivity
- 360° continuous rotation
- 4 wheel steering for more agility
Excellent rough-terrain capabilities
- Oscillating axle for a very good ground grip
- Differential lock (hydraulic) to optimize crossing capacity
- Climb ramps up to 45%
Optimized cost of ownership
- Simple and reliable engine (>19kW, does not require a particulate filter)
- Simplified hydraulic architecture thanks to mechanical axles
- Sherpal ready for maximized usage and to generate additional revenue (optional)
Optimal safety
- Haulotte Activ'Shield Bar: anti-crush system
- Haulotte Activ'Lighting System: load and unload the machine in low visibility conditions
| Working height | 66 ft 8 in |
| Platform height | 60 ft 8 in |
| Horizontal outreach | 39 ft |
| Up and over clearance | 27 ft 11 in |
| Lift capacity | 550 lb unrestricted / 770 lb restricted (2 pers.) |
| Platform size | 8 ft x 3 ft |
| Length | 28 ft 2 in |
| Width | 8 ft |
| Height - stowed | 8 ft 1 in |
| Storage / transport length | 20 ft 3 in |
| Storage / transport height | 9 ft 9 in |
| Platform rotation | 180° (+90° / -90°) |
| Turntable rotation | 360° continuous |
| Tailswing | 1 ft 4 in |
| Wheelbase | 8 ft 2 in |
| Ground clearance | 14 in |
| Tilt | 4° - option 6° |
| Drive speed | 0.3 - 3 mph |
| Maximum wind speed rating | 28 mph |
| Gradeability | 45 % |
| Tires - solid rough terrain | 3 ft x 1 ft 2 in |
| Turning radius - outside | 17 ft 1in |
| Power source | KUBOTA, TIER 4 final : Stage V, China IV, Diesel: 18.5 kW |
| Weight | 20,790 lbs |
| Ground clearance - mini | 11 in |
| Ground clearance - maxi | 14 in |
- Haulotte Activ’Shield Bar
- Haulotte Activ'Lighting System
- Haulotte Stop Emission System
- Haulotte Activ’Screen
- 4 wheel drive and 4 wheel steering
- Permanent limited slip differential
- Oscillating axle
- 360° continuous rotation
- Simultaneous and proportional movements
- Swing out engine tray for ease of maintenance
- Access to the MyHaulotte multi-service portal
- Telematics solutions
- 12 V battery / electrical control system
- Rotating beacon
- Upper control box protection cover
- Haulotte Extra Reach
- Hydraulic generator in 3.7kw or 12kw
- USB port
- Air line to platform
- Cold weather kit
- Glazier kit
- Flashing light
- Sherpal telematics subscription
- Non-marking tires
