Specifications
Excellent maneuverability
- Simultaneous drive and rotation
- Tight turning radius
- Zero tailswing
- Compact stowed height passes through standard doorways
- 3 ft 11 in width
Optimized productivity
- Long working cycles
- Suitable for indoor and outdoor use
- Long working cycles
| Working height | 37 ft 9 in |
| Platform height | 31 ft 9 in |
| Horizontal outreach | 23 ft 2 in |
| Up and over clearance | 15 ft 7 in |
| Lift capacity | 550 lb (2 pers.) |
| Platform size | 3 ft 9 in x 2 ft 7 in |
| Length | 17 ft 7 in |
| Length - transport | 12 ft 8 in |
| Width | 3 ft 11 in |
| Height - stowed | 6 ft 6 in |
| Height - transport | 7 ft 3 in |
| Tailswing | 0 in |
| Vertical jib rotation | 132.2° (+63.5/-68.7) |
| Horizontal jib rotation | N/A |
| Platform rotation | 180° (+90/-90) |
| Turntable rotation | 355 ° |
| Wheelbase | 5 ft 5 in |
| Ground clearance | 5 in |
| Tilt alarm | 3° |
| Drive speed | 0.4 - 3.7 mph |
| Maximum wind speed rating | 28 mph |
| Gradeability | 25 % |
| Turning radius - outside | 12 ft 0 in |
| Tires | 23.5x7.5 |
| Batteries | 48V - 320 Ah (C5) |
| Weight | 15,578 lb |
| Ground clearance - mini | 0 in |
| Ground clearance - maxi | 0 in |
| Ground clearance - mini | 0 in |
| Ground clearance - maxi | 0 in |
- Towing hooks and lifting points
- Descent alarm
- Solid non-marking tires
- 2 wheel drive
- Self-closing swing gate
- Solid state battery charger
- Automatic platform leveling
- AC Power to the platform
- Electronic horn
- Fully proportional controls
- Auxiliary power in the platform for emergency down
- Low voltage interrupt
- Hour meter
- 48 V DC drive system
- Tilt alarm
- Motion alarm (travel and elevate)
- Circuit breaker
- Centralized battery filling
- Telematics ready
- Fluorescent tube caddy
- Orange safety cone holder
- Air line to platform
- Working light
