Presentation
Specifications
| Weight | 23 501 |
| Working height | 69 |
| Platform height | 63 ft |
| Lift capacity | 1654 lb (4 pers.) |
| Lift capacity - extension | 500 lb |
| Platform length - outside | 16 ft 3 in |
| Platform length - extended | 24 ft 7 in |
| Extension length | 4 ft 2 in |
| Platform width - outside | 6 ft 9 in |
| Height - stowed | 11 ft 6 in |
| Height - guardrails lowered | 8 ft 11 in |
| Length | 16 ft 3 in |
| Overall width | 7 ft 11 in |
| Wheelbase | 9 ft 10 in |
| Ground clearance | 12 |
| Auxilliary hydraulic ports | 0.5 mph |
| Drive speed | 2.8 mph |
| Gradeability | 38 % |
| Tilt (longitudinal / lateral) | 3,5° / 1,5° |
| Lift / lower speed | 100 s |
| Turning radius - outside | 14 ft 5 in |
| Tires | 35 X 14 in |
| Batteries (net capacity) | Li-ion: 25.8 hp |
| Hydraulic system capacity | 21.6 gal |
- Range extender (5.2 kW)
- Squawker
- Leak containment system
- Platform plinth access handles
- Material handling rack
- SHERPAL telematics solution
- Cold & arctic weather kits
- Non marking tires
- AC power to platform plug (110 / 230 V)
- Double swing gate entry
- Fast charger (380 V)
- Central tube holder
- Platform lighting
- Haulotte Activ'Shield Bar
- Air line to platform
