Presentation
- 100% electric drive & rough terrain capabilities
- High performance
- Easy maintenance & durability
Specifications
100% electric drive & rough terrain capabilities
- Silent & clean operations: ideal for both indoor and outdoor use
- Manual and automatic differential lock: optimum grip on difficult terrain
- 4-wheel steering (PRO model only): improved maneuverability on all types of terrain
- Upper control box with integrated screen: real-time information
High performance
- Removable Range Extender(optional): extends autonomy with low power consumption
- Platform capacity of 1654 lb
- Full-height drive capability with no load restrictions
- 24 ft 7 in large deck with 2 extensions for extended workspace and outreach
- Self-aligning rear-wheels (PRO model only): improved safety for loading procedures
Easy maintenance & durability
- Lithium-ion batteries with 5-year warranty: extended autonomy, long-lasting performance and zero maintenance
- Activ'Screen: on-board configuration & diagnostic interface
- Easy access to components for fast and efficient maintenance
| Working height | 69 ft |
| Overall width | 7 ft 11 in |
| Platform height | 63 |
| Lift capacity | 1654 lb (4 pers.) |
| Lift capacity - extension | 500 lb |
| Platform length - outside | 16 ft 3 in |
| Platform length - extended | 24 ft 7 in |
| Extension length | 4 ft 2 in |
| Platform width - outside | 6 ft 9 in |
| Height - stowed | 11 ft 6 in |
| Height - guardrails lowered | 8 ft 11 in |
| Length | 16 ft 3 in |
| Wheelbase | 9 ft 10 in |
| Ground clearance | 11 in |
| Auxilliary hydraulic ports | 0.5 |
| Drive speed | 2.8 |
| Gradeability | 38 % |
| Tilt (longitudinal / lateral) | 3,5° / 1,5° |
| Lift / lower speed | 100 s |
| Turning radius - outside | 24 ft 5 in |
| Tires | 35 X 14 in |
| Hydraulic system capacity | 21.6 |
| Weight | 23 369 lb |
| Batteries (net capacity) | Li-ion: 25.8 hp |
| Length of the chassis (without platform) | 0 ft |
| Nominal energy | 21.5 kW.h |
- 4 wheel drive
- 72V Lithium-ion batteries pack with 5-year warranty
- 4 wheel-steer with self-aligning rear-wheels (PRO model only)
- AC motors
- Access to th MyHaulotte multi-service portal
- Telematic solution
- Haulotte Activ'Energy Management: smart battery management system
- Haulotte Activ'Screen
- Haulotte Activ'Lighting System(standard PRO model)
- Dual extensions
- Outriggers with automatic or individual set up
- Folding guardrails
- Manual and automatic differential lock
- Upper control box with integrated screen
- Range extender (5.2 kW)
- Squawker
- Leak containment system
- Platform plinth access handles
- Material handling rack
- SHERPAL telematics solution
- Cold & arctic weather kits
- Non marking tires
- AC power to platform plug (110 / 230 V)
- Double swing gate entry
- Fast charger (380 V)
- Central tube holder
- Platform lighting
- Haulotte Activ'Shield Bar
- Air line to platform
